CPU

12th Gen Alder Lake-U/P/H i3/i5/i7

13th Gen Raptor Lake-U/P/H i3/i5/i7

RAM

1* SODIMM DDR4 3200MHz Max 32GB

Display

Intel UHD Graphics

1* VGA or DP

1*HDMI 2.0,

1*Type C

Network

2* Realtek RTL8111H Gigabit,Support Wake On LAN/PXE

Storage

1* 7pin SATA3.0 6Gbps

1* M.2 Key-M 2280 PCIE X4

Audio

ALC897 7.1,MIC/Line-out,Amplifier (2 ohms, 5W)

Expand

1* Mini-PCIe for WIFI/4G

Front I/O

1* HDMI

1* VGA or DP

2* USB 2.0 (1*Type C Optional)

2* RJ-45

1* 12-19V DC

Rear I/O

1* 3.5mm Audio Line-OUT,MIC in

2* RS232

4* USB3.0

1* Power Button

1* HDD LED

1* COMS

Inside I/O

2* COM RS232/485 Optional,COM2 Support RS422

1* Amplifie 1*4pin

1* USB2.0 Header,Support 2*USB 2.0,Same Lay with LAN2

1* GPIO 2*5Pin

1* SATA Power 1*4Pin

1* 4pin ATX

1* Front Panel 2*5Pin

TPM

1* TPM2.0 2*6Pin,Optional

Working Temp

-10℃～60℃

Storage Temp

-20℃～70℃

Working Humidity

5%-95% relative humidity, no condensation

Size

120mm x 120mm
