CPU

Intel 12th/13th/14th Gen  HX Serial CPU

Intel I7-12700HX/I9-12900HX/I9-13900HX/14900HX,TDP:55W

Graphics

Intel® Iris® Xe Graphics eligible(Integrated on CPU)

Nvidia RTX4070 Mobile VRAM GDDR6 8G Graphics Card

Memory

2*SO-DIMM DDR4 3200MHz,up to 96GB

Storage

1*M.2 2280 for SATA 3.0/NVME PCIE3.0 x4 SSD

1*M.2 2280 for NVME PCIE4.0 x4 SSD

1*SATA 3.0

Network Card

1 or 2 * Intel i226 2.5Gigabit

Expand

1×M.2 2230 for WIFI/BL

Audio

Onboard HD audio chip,1*Line Out,1*Mic

BIOS

256M flash ROM,AMI UEFI BIOS,PXE,WOL

Display

2*HDMI2.0

1×Type-C DP

1x EDP(30pin FFC1/IPEX1)

1*DP 1.4

Rear I/O

1* DC IN(5.5*2.5mm)

1*HDMI 2.0

1*DP1.4

1*Type-C(DP+USB)

2 or 4*USB3.0

1 or 2*RJ45

1*Line Out

1*MIC In

Inside I/O

1*EDP FPC/I-PEX 30 Pin(reserved)

1*HDMI2.0 FPC/I-PEX 30 Pin

1*SATA3.0

1*SATA Power(4PIN)

1×F_Audio

2×RS232(RS485/RS422 Optional)

1*Speaker 2*8 Ω 1W(4Pin 2.0 Wafer)

2*USB2.0

2*USB3.0

1*USB 2.0+1*USB 3.0

1*CPU FAN 4Pin

1*GPU FAN 4Pin

1*LED(DC5V*2,4Pin 2.0 Wafer)

Power Supply

DC19V(Advise more than 230W Power Supply)

ATX 4Pin 19V Optional

Size

210mm(L) X 190mm(W),Height 32mm(with heatsink)

OS

Windows 10/11 / Linux

Working Temp

0℃ to 50℃

Storage Temp

-20℃～70℃

Working Humidity

5%-95% relative humidity, no condensation

Ordering Info

ZC-RTX4070-12700HX Onboard I7-12700HX CPU

ZC-RTX4070-12900HX Onboard I9-12900HX CPU

ZC-RTX4070-13900 Onboard I9-13900HX CPU

ZC-RTX4070-14900 Onboard I9-14900HX CPU
