CPU

Intel 14th Gen Meteor Lake Core Ultra 3 5 7 CPU Optional

Ultra 5 125H,14 Cores 1.2GHz to 4.5GHz

RAM

2* SO-DIMM DDR5 5600MHz DDR4,up to 64GB

Display

Intel Arc graphics,Support DirectX 12.1 OpenGL 4.6,4K

1*HDMI 1.4,Max 4096*2304@24Hz

1*DP,Max 7680*4320 @ 60Hz

1*LVDS/1*EDP(Choose by Jumper)

Network

2*RTL8111H Gigabit Network,Support PXW,Wake on LAN

Storage

2*SATA3.0 6Gbps

1* M.2 2280 NVME SSD PCIE4.0 X4 Signal

Audio

Onboard ALC897

Support MIC/Line-out, power amplifier-4 ohm 3W

Expansion

1*Mini PCIE

1*M.2 Key E 2230

Rear I/O

2* LAN RJ45

4* USB3.0

1* HDMI

1*DP

1*Lini Out,1*Mic In

1* 12V DC

Inside I/O

1*EDP2 (2*15Pins)

1*LVDS (2*15Pins)

1*INVERTER(1*6Pins)

6*COM(6*RS232 Default,COM2/3 Support RS485/422)

1*ATX Power(2*2Pins)

4* USB 2.0 (2*5Pins)

1* SATA Power Pin

1* 4pin SATA Power

1*SIM Slot

1*TPM ESPI Type(2*6Pins)

1*AUDIO(2*5Pins)

1* Front panel switch button and indicator light  2*5Pin

1*Amplifier 1*4Pins

1*DC 12V Jack(1*4Pins)

FAN

1*CPU FAN(1*4Pins),1*System Fan(1*4pin)

GPIO

Support 4 input and 4 output GPIO

Watchdog

Support hardware reset function (256 levels, 0~255 seconds)

OS

Windows 10/11/Linux

Power Supply

DC 12V

Working Temp

-10℃ to 60℃

Storage Temp

-20℃～70℃

Working Humidity

5%-95% relative humidity, no condensation

Size

170mm x 170mm
