ZC-ION4-5200 I5 5200u 4K Display Nvidia GT730 MINI ITX Motherboard

Category:Mini Itx Motherboard

Description:Main Features: 1.Onboard CPU I5-5200U Dual Core 2.2 GHz,Turbo Boost 2.7GHz 2.NVIDIA GT730,2GB Video Memory,Support 4K Playing 3.VGA&HDMI,LVDS,Support Double Display 4.DC 12V Power Supply, Can be Used to More Cases 5.MINI ITX Motherboard (17*17),Suitable for Ma...

Service Hotline:+86-0755-25872280

InquirySkype

Description

ZC-ION4-5200 MINI-ITX Motherboard With I5-5200U Dual Core 2.2 GHz

Turbo Boost 2.7GHz,NVIDIA GT730,2GB Video memory,Support 4K Playing

With VGA,HDMI,LVDS,With 1*SATA2.0,1*SATA3.0,1*RJ-45 LAN Port

MINI PCIE,MINI SATA,SIM Card Slot,DC-12V,Support Total 8*USB.


Main Features:

1.Onboard CPU I5-5200U Dual Core 2.2 GHz,Turbo Boost 2.7GHz

2.NVIDIA GT730,2GB Video Memory,Support 4K Playing

3.VGA&HDMI,LVDS,Support Double Display

4.DC 12V Power Supply, Can be Used to More Cases

5.MINI ITX Motherboard (17*17),Suitable for Majority Cases

6.With MINI SATA,MINI PCIE,SIM Card Slot,Support SSD,WIFI,3G/4G



  ZC-ION4-5200 Motherboard Specification

CPU

Onboard Intel Core i5-5200U

Dual Core 4 Thread 2.2GHz

Turbo Boost 2.7GHz

3MB L3 Cache

TDP only 15W

RAM

2*SO-DIMM DDR3 1600MHz Memory,MAX 16GB

Graphics Card

NVIDIA GT730,2GB Video Memory

Support 4K Playing

SATA

2*SATA Slots

Audio card

Realtek ALC662

Network Card

1*Realtek 8111E

10/100/1000M Network Card

Amplifier

Built-in SPK Ports,Support 2W,3W,5W Speaker

Display

1*HDMI

1*VGA

1*LVDS

LVDS

1*Double Channel 24Bit LVDS

Expansion Slot

1*MINI PCI-E Support SSD

1*MINI PCI-E Support WIFI,3G

Support Both Full Size and Half Size

1*SIM Card Slot

 Rear Panel I/O

2*USB 3.0

2*USB 2.0

1*RJ-45

1*HDMI

1*VGA

1*DC12V_JACK

1*AUDIO Line Out

1*MIC IN

 Internal I/O

1*F-AUDIO1

1*SPDF

1*AUTO Power ON Switch

1*F-USB(Support 2 USB Ports)

1*F-USB1(Support 2 USB Ports)

2*COM PINS

1*GPIO

F-PANEL1

1*F-KB/MS

2*SATA 3.0 Slot

2*SATA Power Slots

1*SYS-FAN1 PWR

1*CPU FAN PWR

1*ATX1 4PINS

1*30PINS LVDS

1*LVDS-CL

1*INVT-PW

1*VGA PINS

Power Supply

12V DC-In

4PIN DC-ATX

Size

MINI ITX(17*17)
