Processor

LGA1700 Socket

Support Intel 12th 13th Generation Intel Celeron/Pentium/I3/i5/i7 CPU

Chipset

Intel H610

Memory

2*SO DDR4 DIMM 3200MHz,Max 32GB

Display

1*LVDS

1*HDMI

1*HDMI

Storage

2*SATA 3.0,6Gbps

1*M.2 Key M 2260/2280 NVME PCIE X4/SATA SSD

Network Card

1*Gigabit LAN,Support Wake-on-LAN/PXE

Audio

Onboard ALC897, Support MIC/Line-out

Expansion Slot

1*M.2 2230

Rear Panel I/O

2*USB 2.0

4*USB 3.0

1*HDMI
1*DP

1*RJ45

1*Audio In

1*Audio Out

Internal I/O

1*JHDMI(2*8pins)

2*USB 2.0(2*5pins)

2*USB 2.0(2*5pins)

1*JCOM1(2*5pins)

2*SATA 3.0

2*SATA Power(1*4pins)

1*LVDS(2*15pins)

1*INVERTER(1*6pins)

1*Speaker(1*4pins)

1*System FAN(1*3pins)

1*CPU FAN(1*4pins)

1*Front Audio(2*5pins)

1*ATX(4 Pins)

1*Front panel and light(2*5pins)

Watchdog

Support hardware reset function (256 levels, 0~255 seconds)

Power Supply

DC12V-19V

Operating Temp

0℃～60℃

Storage Temp

-20℃～70℃

Operating Humidity

5%-95% Relative humidity,non-condensing

OS

Windows 10/11,Linux

Dimensions

Mini ITX ,170mm*170mm
