CPU

Intel® Celeron Baytrial J1900,4 Cores 2.0GHz Burst to 2.42GHz,TDP 10W

RAM

1*SO-DIMM Slo,1600/1333MHz DDR3L/1.35V,Max 8B

Display

Intel® HD Graphics

1* VGA Header

Network Card

4* Intel i211 Gigabit (2 Group Bypass Optional),Support Wake On LAN,PXE

1* Mini-PCIe (Support Half/Full Size,Either-or with LAN4)

Storage

1* MSATA

1* SATA2.0

Rear I/O

4* RJ-45

2* USB 2.0

1* CISCO Standard RS232

1* Power Button

1* Hard Disk/Power Indicator

1* 12V DC

Front I/O

2* USB 2.0 (either-or inside USB header)

4* Network Indicator

1* Hard Disk/Power Indicator

Inside I/O

1* 4pin ATX

1* JVGA 1*12Pin

2* USB 2.0  2*4Pin (either-or rear 2*USB Port)

1* PS2 1*6Pin

1* Network Indicator 2*8Pin

1* SATA Power 1*4Pin

1* Front panel switch button and indicator light interface 2*5Pin

Cooling System

Passive Fanless Cooling

Fan Header

1*4pin CPU fan interface reserved, 1*4pin system fan interface reserved

GPIO

Support 4 input and output GPIO

BIOS

64Mb Flash ROM

Watchdog

Support hardware reset function (256 levels, 0~255 seconds)

OS

Windows 7/Windows 10/Linux

Power Supply

DC 12V

Working Temp

60℃～-10℃

Storage Temp

-20℃～70℃

Working humidity

5%-95% Relative humidity, non-condensing

Size

170mm x 170mm
