Application of Embedded Industrial Motherboard in Portable Ultrasound Diagnostic Instrument

Embedded industrial motherboards have once again introduced new solutions in medical equipment. In the use of portable B-ultrasound diagnostics, an industrial computer with higher performance and better compatibility is required. The core component of an industrial computer is of course the industrial motherboard. The embedded industrial motherboard can well solve the problem of industrial computer in the portable B-ultrasound diagnostic apparatus. Below, Shenzhen Zechuang Weiye will introduce the application of the embedded industrial motherboard in the portable B-ultrasound diagnostic apparatus in detail.

With the rapid development of computer information technology and the needs of clinical diagnosis and treatment, the quality requirements of Embedded industrial motherboards for B-ultrasound images are getting higher and higher, and the scope of ultrasound diagnosis and the amount of information continue to expand. B-ultrasound diagnostic equipment has realized from analog to full digital Change. Therefore, industrial computers are widely used in the medical electronics industry at home and abroad with their advantages of small size, rich interfaces, low power consumption, wide temperature range, and high stability, effectively improving the overall performance and competitive advantages of the B-ultrasound system.

First, Embedded industrial motherboards is small in size and highly integrated; the size of the CMS-4551 (COM) embedded module based on the Cedar Trial Mobil platform is 146mm*80mm.

Second, different models need different Back I/Os, and the interface positions are different; 1. Because of the different mechanism design and layout, the external interface of the portable B-ultrasound may be designed in different positions of the portable B-ultrasound. 2. Because of the different positioning of each manufacturer’s product series, different combinations of the following interfaces may be used: LAN, VGA, TVOUT, USB*2, COM*1, the Multifuction interface of CMS-4551 integrates the above interfaces, and users can follow The organization, layout and the needs of creating personalized products, design the I/O interface board by yourself to realize different I/O combinations. Such as ICN-M206 interface board.

Third, low power consumption, requiring standby time of more than 24 hours and working time of not less than 4 hours;

Fourth, mobile applications require electronic devices to have good shock resistance and shock resistance; the CMS-4551 (COM) embedded module designed based on the Cedar Trial Mobil platform uses on-board CPU and memory, and all internal interfaces use shock and shock resistance. Wafer connector.

Fifth, due to power consumption limitations, the co-processing FPGA function is limited, and the CPU needs to process a large number of video signals;

Sixth, it is required to support 24bits LVDS, VGA, TV-Out display output mode at the same time, Intel? Atom? Cedar Trail processor N2600/2800, single-core power consumption is 3W+1.5W, dual-core power consumption is 3.5W+1.5W , Can support fanless design, provide VGA, DVI, DP and single channel LVDS at the same time, powerful 3D capability, support DirectX10.1 and OpenGL3.0.

Small size, the size of the single board is 146mm*80mm, and the size after adding the interface board is 146mm*105mm.

The introduction of the embedded industrial motherboard will greatly improve the efficiency and effectiveness of the portable B-ultrasound diagnostic apparatus.
